No wiring diagram

[DDlighttruck]

(10-18-2019 )Rawze Wrote:  each of those wires should also be stamped with a number-letter combination. international uses those number-letters to identify circuits, not the wire colors.


I am showing fuse F8-E in the panel as the "skirt light" fuse. Is that what u guys came up with?


if so...

It is wire A54VX (16-gauge brown wire) from the fuse as the +BATT supply line going to pin "A2" on the relay.

The white wire u found should be labelled A54-GX (A54-GXB on the relay), and that is the ground wire for the skirt lights.

A54X and A54XA (also brown wires) are the output of the relay that supplies the lights themselves.

A54XD (also a brown wire) is the control circuit for the relay, and that comes form the body controller itself.



-- maybe this helps a bit.

I don’t have any “E” fuses at all, my skirt lights fuse is F11-D
