Help low boost

[Stir]

When you key on does it go through its travel sweep? You can watch through insite

[gonzo1949]

I just noticed crankcase pressure shows 0.0 and sensor signal voltage is also 0.0. Is this normal?

[gonzo1949]

(02-24-2016 )Stir Wrote:  When you key on does it go through its travel sweep? You can watch through insite

I'm gonna try now

[gonzo1949]

This is what I'm seeing

[gonzo1949]

Also 0.0 crankcase pressure.
0.0 for the cc pressure senor
0.0 for turbo actuator signal sensor

[Marajin]

(02-24-2016 )gonzo1949 Wrote:  Also 0.0 crankcase pressure.
0.0 for the cc pressure senor
0.0 for turbo actuator signal sensor

Those are all normal for that type of tuning

turbo actuator signal sensor > not used by computer because it is J1939 instead.

cc pressure senor/crankcase pressure > not used after that type of custom tuning. unrelated.

[gearhead]

monitor exhaust backpressure turbo speed and boost pressure. See if boost pressure matches your gauge. You will have to convert inhg

[gearhead]

What about the meatured being 0% for the turbo position that's not right. Sounds like wiring or actuator problems.

[gonzo1949]

Boost was 43 hg which is like 22 lbs . That's what the gauge reads. Voltage for the actuator senor reads 0.0 as well .
